Excellent water resistance is the key to the reliable operation of organic bentonite grease in humid environments, thanks to its unique hydrophobic network structure.
The long-chain alkyl groups (such as octadecyl) introduced by organic modifiers form a hydrophobic barrier on the surface of the bentonite layers, effectively preventing water penetration. In the IP 217 water spray test, this grease experienced a mass loss rate of only 5% after 30 minutes of water exposure, while conventional grease exceeded 30%.
In mining machinery applications, even when hydraulic supports have water ingress, the grease maintains a stable structure, extending the lubrication cycle from one month to two months.
Test results show that its anti-emulsification performance meets Grade 1 of the GB/T 7305 standard, with oil-water separation time less than 15 minutes, ensuring rapid restoration of lubrication performance even under conditions of minimal water ingress.
Organoclay in sealant formulations
Organoclay rheological additive Applications
Organoclay for Grease
Organophilic clay CP-720A is a kind of purified and modified organoclay rheological additive, designed especially for using in Grease based on synthetic oils such as vegetable oil, polyester oil. Organic clay has high gelling efficiency, fine thixotropy and perfect anti-settling.
Organoclay in sealant formulations
Organoclay in sealant formulations
Organiclay bentonite CP-720A is used in the following applications:
- Grease Lubricant(the base oil is synthetic oil such as middle-high viscosity petroleum, mineral oil, diester oil, polyester oil, vegetable oil etc.)
- Wood coating
Advantages of Organoclay Rheological Additive
- High efficiency
- The gel is of light colour and high clarity
- Easy to use, no need to pregel
- Organoclay in sealant formulations
- Eliminate polar activator
- Consistent development of rheology
- Can be used to post correct
Properties of Organoclay
Composition Organic derivative of a montmorillonite clay
Appearance Fine powder, light yellow
Moisture content (105℃,2hr) ≤3.5%
Loss on ignition (1000℃) 34%-36%
Bulk density 0.42g/cm3
Fineness (<74μm, %) ≥98%
Organobentonite Packages
Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized.
Organophilic clay Store in a dry, well-ventilated area with temperature of 0℃-30℃. Keep container closed. The quality guarantee period is 24 months.
When it is used in Grease Lubricant, polar activator is needed. Polar activator is acetone/water(95/5). The dosage of activator is 20%-30% of the weight of CP-720A. And also high shear can promote the dispersing of rheology modifier CP-720A.
Adding procedure as follows:
- If condition permits, heat the base oil to 60~70℃
- Add CP-720A while stirring, addition level is 7%-10% of the total formulation. Stir 5~10minutes
- Add polar activator, addition level is 2%-3% of the total formulation. Then add other additives, stir 25~30m
- Use pump to help it pass colloid grinding and homogenizer.
- Deair, filtrate, pack.
Note: With High-speed dispersant of grinding machine, and properly prolong the dispersing time, better gelatin performance can be reached.
The Lubricanting grease which uses organoclay as thickener will own high dropping point, thus can be used under high temperature and presents good impermeability and water resistance.
