Organophilic clay for oil well
Organophilic clay for oil well ： When organic bentonite is applied to oilfield drilling and slurry, we need to take into account the way it is added, mixing conditions, compatibility and its solid content. At the same time, temperature and pH value should also attract our great attention.
These aspects will directly affect the performance of organic bentonite in oilfield drilling mud fluid.
Organophilic clay for oil well
Organophilic clay for oil well
Adding white powdered organobentonite clay to slurry usually disperses it well. We can use specialized feeding equipment to add it evenly to the formulation and mix it to avoid lumping.
Also, it is possible to mix some of the formulation chemicals with the organobentonite clay and then add this slurry to the slurry solution, which helps to improve the overall dispersion of the formulation.
CP-992 Organophilic Clay is a wet process improved viscosifier and gelling agent. It is an easy dispersing, rapid yielding organoclay that exhibits high performance efficiency in diesel oil, crude oil, Low BTEX base oil, mineral oil and synthetic containing base fluid formulation. It is stable and has good suspension and thixotropic features.
Properties
Composition Organically modified bentonite clay
Appearance Off white to tan finely divided powder,
Moisture content (105℃,2hr) ≤3.5%
Particle size (<76μm or 200mesh) ≥98%
Specific Gravity 1.6-1.8
Advantages
- Disperses easily in less time with less shear
- High performance viscosifier for low aromatic, all mineral oil and synthetic base fluids
- Cost- effectively builds viscosity and yield point
- Aids control of fluid loss to the formation
- Increases emulsion stability
- Suspends weighting materials and other solids
- Confers stability at the pressure and temperature 108Pa and 230℃
Application
Base oil:
- Diesel Oils
- Crude Oils
- Mineral Oils
- Synthetic Oil
- Alpha Olefins
- Low BTEX base oil
Viscosifying drilling Fluids:
- Oil based drilling fluids
- Invert emulsion fluids
- Workover fluidsl
- Completion fluids
- Casing packs
- Packer fluids
- Spotting fluids
Safety
All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co., Ltd.
Package
Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized
Storage
CP-992 Store in a dry, well-ventilated area with temperature of 0℃-30℃. Keep container closed. The quality guarantee period is 24 months.
Notice
The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user.
We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.
Organophilic clay for oil well： When we add the organic bentonite to the formula, to carry out rapid mixing and mixing speed and time, the performance of bentonite in the slurry liquid play, there are key factors, we need to have enough mixing speed to avoid organic bentonite agglomeration, they are uniformly dispersed in the slurry, and this speed can not be too high.
Otherwise it will destroy the structure of the organic bentonite itself, and ultimately affect it! performance.
A complete mud formulation has many additives, such as filter loss reducers, viscosity enhancers, lubricants, and so on. The addition of organobentonite can make it more compatible, that is, more compatible, otherwise it will interact with each other and affect the final performance of the mud, so in all the tests we will carry out a compatibility test, to ensure that the organobentonite and other additives can be synergistic presence, to achieve the best performance.
