organic modified bentonite clay

Organoclay | Organophilic Clay CP-2 also named amine treated Bentonite.

In diesel oil based fluids,organophilic clay viscosifier CP-2 are used to increase carrying capacity and suspension properties, providing support for weight materials and improved cutting removal. Organophilic bentonite also aids in filter-cake formation and filtration control.

Properties

Composition                               Organically modified bentonite clay

Physical appearance                Off white to tan free-flowing powder

Moisture content (105℃,2hr)         ≤4%

Particle size (<76μm or 200mesh)    ≥95%

Specific Gravity                                    1.6-1.8

Advantages

Effective viscosifier and gellant

Aids control of fluid loss to the formation

Increases emulsion stability

Improves cuttings carrying and hole cleaning capacity

Suspends weighting materials and other solids

Confers temperature stability to the fluid

Application

Base oil:

Diesel Oils

Crude Oils

Mineral Oils

Synthetic Oil

Viscosifying drilling Fluids:

Oil based drilling fluids

Invert emulsion fluids

Workover fluids

Completion fluids

Casing packs

Packer fluids

Spotting fluids

Package

Organoclay | Organophilic Clay CP-2 is packed in 50lb(22.7kg) or 25kg/bag or customized,multi-wall paper sacks or Kraft paper bag with PE liner or customized.

Storage

CP-2 Store in a dry, well-ventilated area with temperature of 0℃-30℃.  Keep container closed. The quality guarantee period is 24 months.

Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

Internet address: https://www.rheologicaladditive.com/ and email address: [email protected]

Whatsapp / Wechat: +86-13185071071

organic modified bentonite clay

Organic modified bentonite clay

Prior to modification, bentonite is usually subjected to a purification pretreatment. Bentonite purification pretreatment methods include dry purification and wet purification.

Organic modified bentonite clay has good thickening, thixotropy, suspension stability, high temperature stability, lubricity.

Organic modified bentonite clay
The main mineral component of general bentonite is montmorillonite, the content is usually 85-90%.

Our CP series of organically modified bentonite content of active ingredients may be as high as 99.5%, the appearance of milky white micro-fine soft powder, density of about 1.62g/cm³, particle size of less than 1μm. Modified bentonite in the montmorillonite and its organic modified components of the sum.

It should be noted that the content of organically modified bentonite may vary from model to model.

Organic modified bentonite preparation method is the bentonite organic, the use of organic functional groups or organic matter to replace the bentonite layers of exchangeable cations or structural water, and thus the formation of covalent bonding, ionic bonding, coupling bond or van der Waals force bonded organic complex bentonite.

Organic modified bentonite clay

This modification not only increases the distance between bentonite layers, but also enhances the ability to remove organic matter.
Application: designed for high purity requirements occasions, such as electronic materials, pharmaceutical preparations, high-end cosmetics, etc., to protect the safety and effectiveness of products.

In summary, the classification of organic bentonite not only covers the basic types, but also refines the details of specific products such as CP-992, providing comprehensive and accurate solutions for different industrial fields.
