Drilling Grade Organophilic Clay
CP-992 Organophilic clay
CP-992 Organophilic Clay, the wet process improved viscosifier and gelling agent . It is a rapidly dispersing.
- Whatsapp / wechat : 0086-13185071071
organic modification clay is widely used in oil drilling, lubricants, paints and coatings, including water-based and solvent-based paints and coatings, as well as inks and cosmetics.
In China, bentonite mineral resources are very rich, mainly distributed in China’s Xinjiang, Inner Mongolia, Anhui, Guangxi and other places. And the oil drilling field of bentonite accounted for 18% of the entire mineral volume.
So now the development direction of organic bentonite toward more high-end more fine and high quality direction and wider application areas. Every scientific research institutions and manufacturers in the continuous improvement of innovative technology, in a wider range of applications to do continuous efforts.
Organic modified bentonite, mainly through organic cations, such as quaternary amine salt modification, in the interlayer exchange to produce advanced modified bentonite, giving organic bentonite good rheological properties and thixotropic properties and suspension properties.
Organically modified bentonite — commercially known as organoclay — is the non-aqueous form of bentonite clay used as a rheology modifier and anti-settling agent in drilling fluids, coatings, and lubricating greases; full product specifications are at organoclay — the commercial form of organically modified bentonite. The natural bentonite clay properties, including swelling capacity, mineral composition, and industrial grades, are described in bentonite clay — natural properties and modified bentonite grades. To source organically modified bentonite or natural bentonite grades, see organoclay supplier — organically modified bentonite factory.
Organoclay Supplier / Manufacturer :
Internet address: https://www.rheologymodifiers.com/
Email address: [email protected]
Whatsapp / Wechat: +86-13185071071
Organophilic Clay Supplier / Manufacturer :
CP-992 Organophilic Clay, the wet process improved viscosifier and gelling agent . It is a rapidly dispersing.
CP-982 Organophilic Clay is an amine treated bentonite with a moderate temperature performance.
CP-150 Organophilic Clay is a self-activating organoclay that disperses easily and performs well in diesel, low aromatic mineral oil, modified vegetable oil, and synthetic base fluid formulations.
CP-10 organoclay is a rheological additive made of organoclay. It is used in non-polar to moderately polar aliphatic and other solvent systems
CP-MPZ organoclays is an modified bentonite that is used in solvent and resin systems ranging from non-polar to highly polar.
The CP-MPS rheology modifier is a type of organo clay rheological additive that is used in solvent and resin systems ranging from non-polar to high polarity.
CP-EW Organoclay for Water Based paint. It is primarily employed in water borne paint systems,such as latex paint. So it is a good water based additive in paints,coatings,grease etc.
CP-EWS Modified bentonite It is employed in a water-borne coatings system. CP-EWS organoclay outperforms CP-EW in terms of thixotropy, transparence, and dispersion.
CP-WBS Rheology Modifier is rheological modified bentonite. It is mostly employed in water-borne systems.
Organoclay | Organophilic Clay CP-2 also named amine treated Bentonite.
In diesel oil based fluids,organophilic clay viscosifier CP-2 are used to increase carrying capacity and suspension properties, providing support for weight materials and improved cutting removal. Organophilic bentonite also aids in filter-cake formation and filtration control.
Properties
Composition Organically modified bentonite clay
Physical appearance Off white to tan free-flowing powder
Moisture content (105℃,2hr) ≤4%
Particle size (<76μm or 200mesh) ≥95%
Specific Gravity 1.6-1.8
Advantages
Effective viscosifier and gellant
Aids control of fluid loss to the formation
Increases emulsion stability
Improves cuttings carrying and hole cleaning capacity
Suspends weighting materials and other solids
Confers temperature stability to the fluid
Application
Base oil:
Diesel Oils
Crude Oils
Mineral Oils
Synthetic Oil
Viscosifying drilling Fluids:
Oil based drilling fluids
Invert emulsion fluids
Workover fluids
Completion fluids
Casing packs
Packer fluids
Spotting fluids
Package
Organoclay | Organophilic Clay CP-2 is packed in 50lb(22.7kg) or 25kg/bag or customized,multi-wall paper sacks or Kraft paper bag with PE liner or customized.
Storage
CP-2 Store in a dry, well-ventilated area with temperature of 0℃-30℃. Keep container closed. The quality guarantee period is 24 months.
Notice
The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.
Internet address: https://www.rheologicaladditive.com/ and email address: [email protected]
Whatsapp / Wechat: +86-13185071071
organic modification clay
organic modification clay
Organic bentonite produced after modification with bentonite as the main raw material is the mainstream rheological additive and suspending agent in the market, also called thixotropic additive.
It has better water absorption and swelling properties and is used in a wider range of applications, such as in the coatings industry, paint industry, grease industry, cosmetics industry, ink industry, and oil drilling industry.
Organic bentonites exhibit higher yield values and high temperature stability and are used in a wide range of applications. Organic bentonite is also widely used in adhesives, plastics, greases and other composite materials. Organic bentonite itself has a better thickening effect.
organic modification clay
After adding organic bentonite, the leveling of paint coatings, hanging properties can be better improved. Especially the adhesion is better. In terms of improving the suspension of paint, organic bentonite can better prevent the pigment from settling.
Therefore, we use organic bentonite as an anti-settling agent and viscosity builder.
In the water-based system of paints and coatings and solvent-based system of paints and coatings, we will be organobentonite as a kind of anti-sinking agent, rheological agent to use, it is generally added in the amount of 2% to 5% between, it can effectively play the anti-sinking and prevent the effect of particle settling.
organic modification clay
If the use of organic bentonite in the process of adding polar activators, such as ethanol or propanol or propylene carbonate, it will be able to play a better role in the dispersion of the effect and performance can be more comprehensive presentation.
